FEATURES
• Compact size and easy installation
• High efficiency hermetic scroll compressor
• Direct drive condenser fan
• High and low pressure switches for protection of valuable equipment (standard on all units)
• R-410a Refrigerant

Green guard coated on Condenser coils
Corrosion prevention caused by ocean vapor and chemicals which extends coil life span.

Copper fin condenser coil
Fin made from copper, extends life span of condenser coil. Suitable for seaside area and high acidic factory environment.
*Consulting Uni-Aire’s sales engineer for possibility for each location is recommended.

UNIT CASING
• Constructed of zinc-coated heavy-gauge, Galvanized steel
• Powder coated for protection against rust
COMPRESSOR
• Hermetic scroll compressor
• Compressor mounted on vibration isolators
AIR COOLED CONDENSER
• Seamless copper tubes, mechanically expanded into aluminum fins with full height collars
• Leak tested at 600 PSIG from factory
• Dynamically and statically balanced, direct-drive fan
REFRIGERATION PARTS
• Service valves for suction line and liquid line
ELECTRICAL PARTS
• Magnetic contactor for fan motor
• Magnetic contactor for compressor
• High-Low pressure switches
